Our in-house powder coating facility delivers durable, high-quality finishes for fabricated, laser-cut, and manufactured components. Whether you require a single custom part or a large production run, we provide consistent results, excellent corrosion resistance, and a professional finish.
Spraying Capacity
- Maximum Part Size(LxWxH): 7000mm × 2600mm × 2400mm
- Any colour available
- Custom coating thicknesses available
- Suitable for both indoor and outdoor applications
Materials We Powder Coat
We can powder coat a wide range of metal products, including:
- Mild Steel
- Stainless Steel
- Aluminium
- Galvanised Steel
- Zinc-Coated Metals
- Cast Iron
- Brass
- Copper
Typical Applications
- Architectural panels and feature screens
- Laser-cut and fabricated products
- Electrical enclosures and switchboards
- Automotive components
- Outdoor furniture
- Handrails, gates, and fencing
- Industrial equipment and machinery
- Structural steel components
Premium Finishing Services
We offer a range of specialist finishing options, including:
- Colour matching
- Two-tone powder coating
- Custom bolt head powder coating
- Pre-coating sealant application
- Sandblasting and surface preparation (on request)
Express Powder Coating Service
Need parts urgently?
Our 24-hour express powder coating service is available for eligible jobs, helping minimise downtime and keep projects on schedule.
Express service attracts a surcharge. Sandblasting and surface preparation services are not available under the express turnaround option.
5-Stage Surface Preparation Process
The quality of a powder-coated finish starts with proper surface preparation.
Our multi-metal pretreatment process is designed to maximise coating
adhesion, durability, and corrosion resistance across a wide range of
materials.
Pretreatment Tank Capacity
4000mm × 1200mm × 1200mm
Process 1: Degreasing
Using Prelude LGP, a specialised alkaline immersion cleaner designed for steel and aluminium, contaminants such as oils, grease, and manufacturing residues are removed to ensure a clean surface prior to coating.
Process 2: Multi-Metal Passivation
Using SurTec 609GV, an advanced trivalent chromium passivation treatment suitable for steel, aluminium, galvanised steel, zinc-coated materials, and zinc die-cast components. This process creates a uniform nano-coating layer that enhances paint adhesion and improves long-term corrosion protection.
Process 3–5: Rinsing and Final Preparation
A series of controlled rinsing and preparation stages ensure all surfaces are thoroughly conditioned before powder application, delivering a high-quality finish and long-lasting performance.
Instant Quotes
Need pricing fast?
Upload your drawings or specifications and receive a rapid quotation from our team. Instant online quoting functionality is currently being developed to make the process even faster.
